- Long life with warranty up to 10 years
- Vary fabric colors selection
- Low static pressure require just 120 pa
TYPES OF FABRICS
- Trevira
- Combi (Recommended)
- Lite
- Glass
- Poly
There are many different fabric properties for many different applications.
For more information, please visit http://www.fabricair.com/en/fabricair-ducts/fabrics.
FLOW MODELS
- FabFlow™ – the air exits the duct through the permeable fabric surface.
- MicroFlow™ – the air exits the duct via laser cut micro-perforations along the circumference of the duct.
- PerfoFLow™ – the air exits the duct via laser cut perforations along the circumference of the duct.
- SonicFlow™ – the air exits the duct via rows of laser cut perforations.
- OriFlow™ – the air exits the duct via rows of laser cut orifices.
- NozzFlow™ – NozzFlowTM is used in applications where very precise directional airflow is needed.
- JetFlow™ – JetFlowTM is capable of generating exceptionally long throws through the use of conical jets in varying diameters.
For more information, please visit http://www.fabricair.com/en/fabricair-ducts/flow-models.
SUSPENSIONS
FabricAir provides a wide variety of suspension systems. The most selected are as below.
Type 1 – Single Tension Cable (Cable with PVC diameter 3-5 mm. in options of galvanize or stainless steel material)
Type 2 – Double Tension Cables (Cable with PVC diameter 3-5 mm. in options of galvanize or stainless steel material)
Type 3 – Single T-rail Aluminum profile (Install by mounting T-rail to ceiling surface by screws)
Type 8 – Single H-rail Aluminum profile (Install by hanging H-rail with cable hook up to truss/ceiling)
Type 12 – Double T-rails Aluminum profile with Half-round Duct (Install by mounting T-rail to ceiling surface by screws)
For more information, please visit http://www.fabricair.com/en/suspensions.
Recommended Fabric
- Combi 20 – for cost optimum
- Combi 30 – for non-permeable (Evaporative cooling application)
- Combi 80 – for anti-microbial
Combi Fabric Color
1. White 2. Blue 3. Orange 4. Dark Gray 5. Black 6. Red 7. Light Gray 8. Green 9. Tan/beige
To see color of Combi fabric, please visit https://www.fabricair.com/sites/default/files/4182-color-combi.pdf
Our Strong Points
Our FabricAir® supply duct could be designed in complicated duct layout with header, 90°, 45°, or any degree turns, reduce, and else. All duct sections are connected together by removable zippers
